Gigagain TISO7 Isolated Variable Power Supply
- In Stock
- 7 fully isolated DC outputs using Pure Two-Stage Switching Power Supply topology
- Each output independently switchable between 9V/12V/15V/18V
- Outputs 1 and 4 support positive/negative polarity switching for reverse-polarity vintage-style pedals
- 24V AUX output for expansion; independent current-limit indicator LEDs per channel
- Suits both digital and analog effects pedals
Gigagain TISO7 Isolated Variable Power Supply
The Gigagain TISO7 is a high-performance power solution engineered specifically for modern, complex pedalboards. Built around a pure two-stage switching topology, the TISO7 delivers clean, uncompromised power to eliminate the unwanted noise, hum, and crosstalk that frequently plague multi-pedal setups, ensuring your true tone shines through with absolute clarity.
Pure Two-Stage Isolation Technology
Unstable stage power and mixing power-hungry digital processors with sensitive analog pedals often leads to devastating ground noise and interference. The TISO7 solves this by providing a true isolated architecture across all outputs. Activating like an independent "soundproof cabin" for each pedal on your board, this advanced circuit isolates each power line to completely eradicate ground loops and high-frequency howling for a worry-free performance.
High-Current Output with Switchable Voltages
Equipped with a 7-channel true isolated DC output design, the TISO7 is built to easily handle modern flagship digital gear. Each of the 7 channels delivers up to 6W of power, translating to a massive 660mA at 9V to effortlessly drive high-draw effects. For maximum pedalboard compatibility, each channel features switchable voltage settings, perfectly scaling its rated current across multiple standards: 9V (660mA), 12V (500mA), 15V (400mA), or 18V (330mA).
Built-In Polarity Switching
Say goodbye to searching for reverse-polarity adapter cables or carrying separate adapters for vintage-style effects. The TISO7 features integrated switchable polarity on Channels 1 and 4. With a simple flip of a switch, you can instantly alter the channel's polarity to safely power centre-positive pedals alongside standard centre-negative gear without needing extra dongles or custom wiring.
Smart Monitoring and Visual Risk Prevention
To prevent unexpected power failures on stage, the TISO7 features an intelligent, individual multi-colour power limit indicator system. Each channel is constantly monitored in real time. If a channel begins to approach its limit, a clear three-colour risk advisory warns you in advance, while an over-current draw triggers a flashing white light. This visual alarm lets you pinpoint exactly which channel is overloaded so you can adjust your setup safely before a performance accident occurs.
(19819)
The Tech Features
Brand: Gigagain
Model: TISO7
Outputs: 7 x True Isolated Switchable DC
- 7 x switchable 9v/660mA, 12v/500mA, 15v/400mA or 18v/330mA
- Channels 1 and 4 feature switchable polarity
- 1 x Aux Output 24v DC daisy-chain output (2000mA max)
Features:
- Pure Two-Stage Switching Power Supply Topology
- Independent three-colour power limit LED indicators per channel
- 6W maximum power per channel
- Output over-voltage protection
- Output reverse polarity protection
Dimensions: 124.5 L x 90.2 W × 22.6 H (mm)
