Nux NAI5 Optima Air Acoustic Guitar Preamp/DI with IR Loader

The Nux Optima Air is a dual-switch acoustic guitar simulator with a preamp for acoustic and electric guitars. It simulates any acoustic guitar tone, and converts it into an IR file with the best-optimized sound, depending on your guitar and pickup type.

NUX Optima Air has a unique profile capture function, so you can create your own acoustic guitar profile (IR file) by capturing your favorite acoustic guitar's sound. The IR loader is combined with a pre-amp that allows you to fine-tune your sound with a 3-band equalizer. There’s also an extra one-knob-control Reverb Effect. Attach any effect pedal using the SEND/RETURN effect loop, and add the Optima Air into the signal chain.

There is an XLR DI output for direct line/mixer connection, headphones output for silent play, and auxiliary input to connect and play along to a music player.

Features and Knob Functions:

  • IR Level: Adjusts the simulated signal (Impulse Response file)
  • LEVEL Select (Push to Save): In manual mode, you can choose the IR file. And you can save your customized preset by pushing the knob
  • Gain: Adjusts the signal input Gain level

3-Band EQ:

  • Bass: Adjusts the low-frequency level
  • Middle: Adjusts the middle-frequency level
  • Treble: Adjusts the high-frequency level

IR Footswitch:

  • Manual Mode: Engage/disengage the selected IR file. Acoustic guitar simulation ON/OFF
  • Preset Mode: Bank Down. Also, if you are editing a preset, you can push the IR footswitch to exit without saving

AMP Footswitch:

  • Manual Mode: Activates the pre-amp section. When you engage the AMP, you can use the Gain and the 3-band EQ
  • Preset Mode: Bank Up. Also, If you are editing a preset, while changing the preset name, you can push the AMP footswitch and move the cursor to the next selection area to choose a letter, number or symbol

The Tech Features

Brand: Nux

Model: NAI5 Optima Air

Sampling Quality: 24-bit, 48kHz

Built-in Profiles: 15 Acoustic Guitar Profiles with IR Level Control

Presets Slots: 9

EQ: Gain, Bass, Middle, Treble

Send/Return: 6.35mm (1/4 inch)

Input/Output: 6.35mm (1/4 inch)

DI Out: Male XLR

Aux-in and Headphone Input: 3.5mm (1/8-inch)

USB Port: Micro B USB Port for Audio Stream and Software Updates

Dimensions: 10.5cm x 11.5cm x 5.8cm

Weight: 420g

Current Draw: < 200mA

Power Supply (Not Included): 9v DC Center Negative
